Dx52D Galvanized Coil
Galvanized steel coils
Grade: zinc layer thickness 15g, 60g, 80g, 120g, etc.
+86 13370536338
+86 13370536338
sales04@tai-pu.com
Contact Us

◉ Product Details

Products Description
Galvanized steel sheet price hot-dip galvanized steel coil ppgi
Galvanized steel coil, immersing the thin steel plate in the molten zinc bath, and adhering a layer of zinc thin steel plate on the surface. It is mainly produced by the continuous galvanizing process, that is, the coiled steel plate is continuously immersed in the zinc-melted plating tank to make galvanized steel plate; alloyed galvanized steel plate. This kind of steel plate is also made by the hot-dip method, but it is heated to about 500 °C immediately after exiting the tank to form an alloy film of zinc and iron. This galvanized steel coil has good paint adhesion and weldability.
Product Name
Galvanized Coil
Material
Dx51D, Dx52D, Dx53D, DX54D, S220GD, S250GD, S280GD, S350GD, S350GD, S550GD; SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490,
SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC340 , SGC490, SGC570; SQ CR22 (230), SQ CR22 (255), SQ CR40 (275), SQ CR50 (340), SQ
CR80(550), CQ, FS, DDS, EDDS, SQ CR33 (230), SQ CR37 (255), SQCR40 (275), SQ CR50 (340), SQ CR80 (550); or Customer’s Requirement
Thickness
0.12-6.00mm or customer's requirement
Width
600mm-1500mm, according to customer's requirement
Zinc coated
30g-275g/m2
Type of Coating
Hot Dipped Galvanized Steel
Surface Treatment
Passivation(C), Oiling(O), Lacquer sealing(L), Phosphating(P), Untreated(U)
Surface Structure
Normal spangle coating(NS), minimized spangle coating(MS), spangle-free(FS)
Coil ID
508mm or 610mm
Coil Weight
3-20 metric ton per coil
Standard
JIS 3302 / ASTM A653 /EN10143 AISI , ASTM , DIN , GB , JIS G3302 G3312 G3321 , BS
Technique
Hot Rolled / Cold Rolled
Product Application
1. Fence, greenhouse, door pipe,greenhouse

2. Low pressure liquid, water, gas, oil, line pipe

3. For both indoor and outdoor the building construction

4. Widely used in scaffolding construction which is much cheaper and convenient
Origin
Shandong China
Certificates
API ISO9001-2008,SGS.BV
Delivery Time
Usually within 10-45 days after receipt of advance payment
Cold Rolled Steel Reduction is the process of reducing thickness of hot roll pickled strip to lower target gauge points. Steel Warehouse uses a reversing mill and a complex automation system to target precision gauge points. Our cold reduction mill services make steel harder and stronger. This process is called work hardening.  Subsequent heat treatment is necessary if the application requires formability. Cold reduction improves gauge inconsistencies in hot roll and allows precision gauge tolerances as tight as +-.0005”. Cold reduction imparts surface texture giving the steel sheet a specific roughness and luster depending on the application. Shape can also be corrected or induced during this process

THE PRODUCTION PROCESS


Chemical Composition
Galvanized Steel 0.18mm-20mm thick galvanized steel sheet 2mm thick Hot dip galvanized steel sizes galvanized sheet metal roll
Grade
C
Si
Mn
Cr
Ni
304
≤0.07
≤1.00
≤2.0
18.00~20.00
8.00~10.50
304L
≤0.030
≤1.00
≤2.0
1 8.00~20.00
9.00~13.00
310S
≤0.08
≤1.00
≤2.0
24.00~26.00
19.00~22.00
316
≤0.08
≤1.00
≤2.0
16.00~18.00
10.00~14.00
316L
≤0.03
≤1.00
≤2.0
16.00~18.00
12.00~15.00
321
≤0.08
≤1.00
≤2.0
17.00~19.00
9.00~13.00
904L
≤0.02
≤1.00
≤2.0
19.00~23.00
23.00~28.00
2205
≤0.03
≤1.00
≤2.0
22.00~23.00
4.5~6.5
2507
≤0.03
≤1.00
≤1.20
24.00~26.00
6.00~8.00

Substrate Type

1.Hot-dip galvanized color coated steel sheet(prepainted galvanized steel sheet)The product obtained by coating an organic coating on a hot-dip galvanized steel sheet is a hot-dip galvanized color-coated plate. In addition to the protective effect of zinc, the hot-dip galvanized color-coated sheet also protects against rust and has a longer service life than hot-dip galvanized sheet; 2.Hot-dip aluminum-zinc color coated sheet(prepainted galvalume steel sheet)Hot-dip aluminum-zinc steel sheets can also be used as color-coated substrates (55% AI-Zn and 5% AI-Zn); 3.Electroplated zinc color coated sheet The electro-galvanized sheet is used as the substrate, and the product obtained by baking with the organic coating is an electrogalvanized color-coated plate. It has a beautiful appearance and excellent processing properties, and therefore can be mainly used for home appliances, audio, steel furniture, interior decoration, and the like.

Coating Type

Polyester (PE): Good adhesion, rich colors, wide range in formability and outdoor durability, medium chemical resistance, and low cost. Silicon modified polyester(SMP): Good abrasion resistance and heat resistance, as well as good external durability andchalking resistance, gloss retention, general flexibility, and medium cost. High Durability Polyester(HDP): Excellent color retention and anti-ultraviolet performance, excellent outdoor durability and anti-pulverization, good paint film adhesion, rich color, excellent cost performance. Polyvinylidene Fluoride(PVDF): Excellent color retention and UV resistance, excellent outdoor durability and chalking resistance, excellent solvent resistance, good moldability, stain resistance, limited color, and highcost.

Galvanized Steel Coil

Spangle is formed during the hot-dip galvanizing process. The size, brightness, and surface of spangles mainly depend on the composition of zinc layer and the cooling method. According to the size, it includes small spangles, regular spangles, big spangles, and free spangles. They look different, but the spangles almost will not influence the quality of galvanized steel. You can choose according to your preference and purpose.
product testing
Application areas
(1)In the construction industry: to manufacture exterior and Interior products such as metal shingles, corrugated sheeting, sandwich panels, profiles, metallic ceilings, skirting boards, decorative panels inside heated and non- heated rooms, elevators, doors window shutters, shelves etc. (2)In the automotive industry: to manufacture external and internal car body parts (car doors, car boots, oil filters, dashboards, windscreen wipers etc. (3)In manufacture of home appliances, furniture, and consumer goods: metallic furniture, lighting equipment, shelves, radiators, сar doors, car boots etc.


◉ Certificate

◉ Company Strength

Shanghai Taipu lnternational Company Is an integrated enterprise integrating sales processing, cutting and transportation.
Our company is committed to provide one stop procurement service for customers all over the world. Our main products are stainless steel, copper, carbon steel, aluminum, galvanized steel, steel sections, steel pipes, color coated products and so on.
Taipu lnternational company includes business department, finance department, storage department, processing department and transportation department which include self-provided trucks, cranes and automatic cutting and semi-finished products.
